How to open / disassemble Sony Walkman NWZ – B133F

sony walkman nwz b133 (10) sony walkman nwz b133 (9)
I was not using my Sony walkman for last 3 months.
After keeping it  idle for three months, finally one fine morning I pick it up for my exercise regime (which I was planning for the last 6 Yrs), to find out it was not working.
I think the battery discharged beyond its safe limit. As every cell requires a minimum residual charge to pickup the charge. Even though it was not switching on, transferring of files to the device or upgrading the software was not an issue, as it was getting detected on computer.
I searched internet for opening procedure of the device for disassembling it, as I could not find any screws or locking mechanism. After trying all the method and staring the device a lot, I got frustrated and break open it.


sony walkman nwz b133 (1) sony walkman nwz b133 (2) sony walkman nwz b133 (4) sony walkman nwz b133 (5)
The green stuff sticking outside is the battery.

Opening procedure
sony walkman nwz b133 (6) Remove the pink panel as shown in the image (marked with red circle). There are two small screws (circled in red colour on the walkman). The pink panel is fixed on the walkman with adhesive. remove it using a thin screw driver.
sony walkman nwz b133 (7) Remove the second panel as shown in the image.
sony walkman nwz b133 (8) All the four screws are marked with red circles. and both panels are also shown in the image. After removing the screws, walkman can be easily opened.

16 thoughts on “How to open / disassemble Sony Walkman NWZ – B133F

  • May 16, 2011 at 5:53 pm
    Permalink

    Hi, Iam from Argentina, a friend of mine broke the USB connect and I wanted to fix. Then i started to remove the lid with a screwdriver from aside, and i notice it was very thing to do, so i founded this post and I realize about the 4 four screws so THANX YOU FOR THE INFORMATION YOUR EXPERIENCE AND TIME! Its already fixed and running 😀 ;D.

    PD: sorry about my writen english, need some fixes too 😛

    Reply
  • May 17, 2011 at 4:30 am
    Permalink

    That's great ammiel, i ruined mine finding this out. thanks, atleast this post is helping someone. I searched a lot before breaking mine

    Reply
  • August 20, 2011 at 6:09 am
    Permalink

    Thanks. Mine was accidentally washed (in my pocket) this morning, and this helped me get it open so I could dry it out 🙂

    Reply
  • March 27, 2012 at 8:32 pm
    Permalink

    can u replace the battery any1 now thnxx

    Reply
    • March 28, 2012 at 1:54 am
      Permalink

      Sure you can, get it replaced from sony shop or you may buy it from batterymart.com or ebatts.com and replace yourself. it costs around $10

      Reply
    • March 28, 2012 at 1:56 am
      Permalink

       Sure you can, get it replaced from sony shop or you may buy it from
      batterymart.com or ebatts.com and replace yourself. it costs around $10

      Reply
      • September 19, 2014 at 1:15 pm
        Permalink

        I have have an prblm that i have connected the mp3 in pc for charging and then after charging press the open button and after pressing the button i have seen walking written on the screen and not open the menu and automatically switch off..so anyone plzz suggest me the solution

        Reply
  • June 8, 2012 at 9:21 am
    Permalink

     thank you for posting that,
    I really love this mp3 player (it fell from 4th floor on a concrete, dive into a bath and after all these adventures it still worked! I suppose that I’ll never find a player like that)
    but now i have o problem when trying to connect to usb – sometiomes it “disappear” – i guess i will have to check what’s going on inside, so thank for showing me how to get in there!

    Reply
  • June 29, 2013 at 7:49 pm
    Permalink

    thanks a lot for explained how to open. good work.

    Reply
  • June 29, 2013 at 7:51 pm
    Permalink

    is it possible to upgrade the memory or not?

    Reply
  • July 5, 2013 at 10:18 am
    Permalink

    Where to find the battery in India? I mean, is there any indian website which sells the battery? Plss help…

    Reply
    • July 13, 2015 at 9:33 am
      Permalink

      As Per sony Repair Centre in Chennai they will not touch the device with the longest pole.They are also unhelpful to the core to know where the battery can be bought!
      Very poor after sale service for Sony Walkman even if you are a DIY buff.
      Therefore I recommend that you make a parallal connection outside the device by proper extension and proper supporting(Jugad) and connect a Li Ion Battery of any Mobile phone properly.That way you will have a long service between recharges,But slightly bulkier.That’s Swachch Bharath!

      Reply
  • November 15, 2013 at 12:12 pm
    Permalink

    Thnx m8 , u have beenreally supportive. Keep up the good work

    Reply
  • November 19, 2015 at 4:33 pm
    Permalink

    THANK YOU!!!
    thanks a lot!!

    I have been trying to open it up for a year. This is really helpful. What kind of screw driver should i use?

    The guys at the sony centre said they wont touch it!

    They wont open up and repair anthing!!

    Reply
